- Engine model
- V1505-BG-ES01
- Emission regulation
- EU Stage V
- Type
- Vertical, water cooled 4-cycle diesel engine
- Cylinders
- 4
- Bore and stroke
- mm (in)
- 78.0 x 78.4 (3.07 x 3.09)
- Displacement
- L (cu.in)
- 1.498 (91.41)
- Aspiration
- Naturally aspirated
- Aftertreatment
- -
- Stand-by output / speed*1
- kW (HP) / rpm
- 16.4 (22) / 1800
- Continuous output / speed*2
- kW (HP) / rpm
- 16.4 (22) / 1800
- Combustion system
- Indirect injection
- Fuel system
- In-line pump
- Length x Width x Height*3
(without aftertreatment unit) - mm (in)
- 601 x 391 x 607 (23.7 x 15.4 x 23.9)
- Length x Width x Height*4
(with aftertreatment unit) - mm (in)
- -
- Dry weight
- kg (lb)
- 127 (280)
