- Engine model
- V2607-DI-E3B
- Emission regulation
- EPA/CARB interim Tier 4 level + EU Stage IIIA
- Type
- Vertical, water cooled 4-cycle diesel engine
- Cylinders
- 4
- Bore and stroke
- mm (in)
- 87.0 x 110.0 (3.43 x 4.331)
- Displacement
- L (cu.in)
- 2.615 (159.6)
- Aspiration
- Naturally Aspirated
- Aftertreatment
- -
- Rated output / speed*1
- kW (HP) / rpm
- 36.5 (48.9) / 2700
- Maximum torque / speed*1
- Nm (lb-ft) / rpm
- 170.0 (125.4) / 1600
- Combustion system
- Direct Injection
- Fuel system
- In-line pump
- Length x Width x Height*2
(without aftertreatment unit) - mm (in)
- 623 x 481 x 640 (24.5 x 18.9 x 25.2)
- Length x Width x Height*3
(with aftertreatment unit) - mm (in)
- -
- Dry weight
- kg (lb)
- 225 (496)
