| Weight | 500 kg |
|---|---|
| Dimensions | 92 × 67 × 102 cm |
| Condition | Cummins original new |
| Warranty | 12 months |
| Packing | wooden case |
-
-
- Advanced design and manufacturing make the engine delivers superior performance and lower cost than competitive engines.
- As compacted yet durable and dependable engine,B series engine contains up to 40% fewer parts than competitive engines in its class. This results in a better power-to-weight ration, a less chance of failure and lower repair cost.
- The turbocharger with wastegated design optimizes operation across the torque curve resulting in excellent low-end torque
General data of DCEC EQB140-20 Diesel Engine for Truck/Coatch Engine Model DCEC EQB140-20 Engine Type 4 stroke, 4 cylinder in line Displacement 3.9 L Bore&Stroke 102*120 mm Net Weight(with flywheel and alternator) 343 KG Center of gravity from front face of block 328 mm Center of gravity above crankshaft centerline 155 mm Technical data of DCEC EQB140-20 Diesel Engine for Truck/Coatch Emission Standard EURO II Fuel System BOSCH Pump Aspiration Turbocharged and Air-Air Intercooled Compression Ratio 17.3:1 Coolant Capacity 7 L Idle Speed 750 RPM Maximum No-load Speed 3150 RPM Maximum Super Speed 4200 RPM Performance Date of DCEC EQB140-20 Diesel Engine for Truck/Coatch Rated Output 103KW/140HP @ 2700 RPM Max Output 112KW Max Torque/Speed 502N.m @ 1500 RPM Torque/Rated speed 365N.m @ 2700 RPM Fuel Consumption/Rated Speed 234 g/KW.h @ 2700 RPM Minimum Fuel Consumption 210 g/KW.h @ 1900 RPM SWAFLY MACHIENRY EQUIPEMENT is a leading supplier of new and used parts since 1984 for the major manufacturers of excavators, wheel loaders, bulldozers,forklifts, and skid steers.
