Description

• • • Advanced design and manufacturing make the engine delivers superior performance and lower cost than competitive engines.
    • As compacted yet durable and dependable engine,B series engine contains up to 40% fewer parts than competitive engines in its class. This results in a better power-to-weight ration, a less chance of failure and lower repair cost.
    • The turbocharger with wastegated design optimizes operation across the torque curve resulting in excellent low-end torque

    General data of DCEC EQB140-20 Diesel Engine for Truck/Coatch
    Engine Model	DCEC EQB140-20
    Engine Type	4 stroke, 4 cylinder in line
    Displacement	3.9 L
    Bore&Stroke	102*120 mm
    Net Weight(with flywheel and alternator)	343 KG
    Center of gravity from front face of block	328 mm
    Center of gravity above crankshaft centerline	155 mm
    Technical data of DCEC EQB140-20 Diesel Engine for Truck/Coatch
    Emission Standard	EURO II
    Fuel System	BOSCH Pump
    Aspiration	Turbocharged and Air-Air Intercooled
    Compression Ratio	17.3:1
    Coolant Capacity	7 L
    Idle Speed	750 RPM
    Maximum No-load Speed	3150 RPM
    Maximum Super Speed	4200 RPM
    Performance Date of DCEC EQB140-20 Diesel Engine for Truck/Coatch
    Rated Output	103KW/140HP @ 2700 RPM
    Max Output	112KW
    Max Torque/Speed	502N.m @ 1500 RPM
    Torque/Rated speed	365N.m @ 2700 RPM
    Fuel Consumption/Rated Speed	234 g/KW.h @ 2700 RPM
    Minimum Fuel Consumption	210 g/KW.h @ 1900 RPM
